Re: Ilizarov vs Orthofix
Tommy Bacal 24 Апрель 2006, 20:04
|
As a student of the ilizarov and orthofix devices I must say that their use is knowledge and experience based. Indeed. Ilizarov is better in 3 dimension control but tends to be more cumbersome. However, the patient's compliance is a result of his appreciation of his care giver. They approve of the ilizarov ex fix just as easily when given the proper explanation.
Your choice of treatment should express your experience.
Bacal tommy
israel
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: John Wood 24 Апрель 2006, 20:49
|
Tommy the best of both worlds - the Taylor Spacial frame! Ilizarov in the 21st century
John Wood
London UK
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: Tommy Bacal 25 Апрель 2006, 00:12
|
I must confess ignorance. I will look it up
Bacal tommy
israel
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: Tommy Bacal 25 Апрель 2006, 00:16
|
Seen picture of taylor spatial frame. Sorry, no experience with this device, but looks interesting.
As I said before, choice of treatment should express the care giver's knowhow.
No human experiences without consent (lol)
Bacal tommy
israel
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: Nicola Papapietro 25 Апрель 2006, 00:21
|
I have just met (and had a very good dining with him and his girlfriend) Dror Paley from Baltimor at the last International Congress of the Mediterranean Orthopedic Surgeon (Ortho Mare Nostrum) at Tanger, Morocco. He showed us those incredible results obtained with the Taylor Spatial Frame in some really incredible cases of
deformities of legs, femoral agenesia and limb lengthening. I have been really impressed. But I think that the Taylor is an "occuping space" and uncomfortable device, justified only in case of major deformities correction.
The cost of Taylor spatial frame I suppose is equivalent to orthofix. I know now, from your answer, that Ilizarov is really cheap compared to orthofix or taylor.
Nick
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: Alexander Chelnokov 25 Апрель 2006, 01:08
|
> incredible results obtained with the Taylor Spatial Frame in some
> really incredible cases of deformities of legs, femoral agenesia and
> limb lengthening. I have been really impressed.
The deformities have been corrected successfully with the Ilizarov technique for about 50 years. Really ANY results achieved with TSF are reachable with the Ilizarov, and often with less cumbersome frame - but not vice versa. BTW a similar hexapod was developed for the Ilizarov set. You can find in outstanding D. Paley's book "Principles of deformity correction" many examples of using Ilizarov, TSF and other devices for same problems.
> But I think that the Taylor is an "occuping space" and uncomfortable
> device, justified only in case of major deformities correction.
Despite it is really huge it is so attractive (especially for people without experience with Ilizarov) because it presents no brainer technique - just apply a frame, input distances to the software and have a "cheque" with tempo for every nut at the distraction rods.
While with classic Ilizarov one must realize oneself what he plans to do, where is axis of rotation, where and how place hinges, spend time to frame reassemblies if all components of the deformity were not addressed simultaneously.
Of course TSF is a real step to the future. Some day a computer will not only calculate correction, but recognize deformity, apply a frame and then control transformation. Surgeons will only worry about how to spend all the money :-)
> The cost of Taylor spatial frame I suppose is equivalent to
> orthofix. I know now, from your answer, that Ilizarov is really
> cheap compared to orthofix or taylor.
I am not sure - maybe in the price list of Smith & Nephew it is close to others. In our setting it is rather cheap. Simple materials, simple parts.
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: Myles Clough 26 Апрель 2006, 00:43
|
I've never used it but have seen the results and I think the concept is most intriguing. The disadvantage is the expense but US hospitals throw away these devices after use on one patient, so there must be a mechanism for distributing them to where they are needed.
You apply the frame then take an Xray, measure the remaining deformities, angulation, translation, rotation and shortening etc. Then feed these parameters into a computer program (on line) and it returns the adjustments that must be made to each of the 6 expansion devices. I hope Smith and Nephew will forgive my copying the image from their page
This is copied from http://ortho.smith-nephew.com/ca_en/Standard.asp?NodeId=2945 which has surprisingly little further information
The literature on this device is quite extensive now. A PubMed search for "Taylor spatial frame" yields 15 articles 12 of which are on subject. The full URL is
http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?cmd=PureSearch&db=pubmed&details_term=taylor%5BAll%20Fields%5D%20AND%20spatial%5BAll%20Fields%5D%20AND%20frame%5BAll%20Fields%5D
Myles Clough mylesclough@shaw.ca
Orthopaedic Surgeon, Kamloops, BC, Canada
Clinical Instructor, University of British Columbia
Editor, OWL (Orthopaedic Web Links) http://www.orthopaedicweblinks.com
Orthogate Workshop Pages http://www.orthogate.com/clough/index.htm
|
[
Ответить ]
|
|
Re: Ilizarov vs Orthofix
Leonid Solomin 24 Апрель 2006, 20:07
|
Dear Dr. Nicola Papapietro MD:
If you:
1. "have some experience in treating fractures but also ostheotomy for varus or valgus knee, for Salter-Harris type of lesion ot the ankle and I have obtained very good results"
2. sure, that Orthofix is "more technological kind of external fixators", "The Orthofix and many others are thin and well accepted by patients",
that it means, that you have no need to use Ilizarov frame for all these cases.
It is possible, if you will start to treat patients with nonunions and false joints,
multiplanar deformations, defects, etc., your attitude to Ilizarov device will be changed.
Best regards,
Leonid Solomin
Leonid N.Solomin, MD, PhD
Head of ExFix Department
R.R.Vreden Russian Research Institute of Traumatology and Orthopedics
8 Baykova Str., St.Petersburg, 195427, Russia
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Alexander Chelnokov 24 Апрель 2006, 21:22
|
NP> fragments in all 3 planes of the space but is a very big kind of
NP> device
What about Taylor Spatial Frame?
NP> and I think there is little compliance by the patient. The
NP> Orthofix and many others are thin and well accepted by patients.
If 1)it is available and 2)it is enough, Orthofix (and many other "prefabricated" frames) are quite acceptable. Ilizarov is not an external fixator but a set of multipurpose details for osteosynthesis according to the principles of Ilizarov. Using the set one may assembly any needed frame - circular, monolateral, hybrid, with
hinges... Any bone or joint can be addressed. Because of its versatility Ilizarov system is dominating over any predefined construction.
Many hospitals which already have Ilizarov sets just reuse them and feel lack of motivation to acquire another solution for a problem already solved with the existing equipment. Especially if instead of a single Orthofix frame one may obtain a truck of Ilizarov rings, bars, posts etc :-)
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Jacob Odesky 25 Апрель 2006, 09:03
|
Dear colleges! I would like to present a Hexapod Ilizarov external fixator.
The Hexapod represents the kinematic mechanism that realizes the three dimensional movements by
different lengths of the six distractors connected to the two platforms. It’s well known in technique
and uses for imitation of flying and other machines.
The system has been developed in Germany and first presented at the Ilizarov meeting in 1995 by Dr. K. Seide. It consists of six telescopic distractors of varying length from 105-235 mm, 6 y adaptors, a measuring stick and software. The Y adaptors can be utilized with all types of the Ilizarov rings. It is possible to place the adaptors freely along the rings as necessary. The connection between the Y adaptors and the distractors is through a universal ball and socket joints. The software is very simple to use and does not need any connection to the Internet. The base data needed includes the diameter of
the upper and lower rings, the positions of the Y adaptors on each ring and the length of the
distraction rods. After the input of this data into the computer, the program shows the initial
position of center of the upper ring in relation to the lower. From this point, all adjustments are
made with specific reference to the central point of the lower ring, since this ring remains in a static position. All adjustments can be in three planes. The CORA is entered in relation to the center of the distal ring and the desired correction entered into the computer.
The software then makes the appropriate adjustments for deformity correction consistently for each plane according to the plan developed on the basis of the malalignment test along three axes with six degrees of freedom.
The software displays a plan for correction detailing the steps according to the surgeons input of the number of days and steps desired. Beyond this, the software determines the final length of the distractors and the changes between the rings so that the progress and changes can be monitored to assure that the changes have occurred appropriately along the scheduled plan.
There is no necessity to establish Hexapod in operation room, it application and removal is quick, taking only about fifteen minutes for each procedure, and is pain-free.
After removal, it is possible to put it to the following patient, thus, having 3-4 Hexapod sets it is possible to treat consistently big number of patients. I, for example for a year having 2 sets, have applied them 21 times.
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Odessky Jacob M.D. 27 Апрель 2006, 17:28
|
Dear Nicola! I have asked us why we prefer the Ilizarov external fixator instead of the modern Orthofix that is for quite all purpose in trauma (according to you experience) and in selected orthopedics problems. What is the reason, if one, to use the Ilizarov instead of the more technological kind of external fixators?
I▓ll try to answer this question very simply. I prefer Ilizarov▓s device because biomechanically, clinically and practically it▓s much better than Orthofix!
I incur to tell greater - the Ilizarov Ex. Fix. augmented by Hexapod Set better not only Orthofix, but also the Taylor Spatial Frame.
2005-09 (ס
12KB (12366 bytes)
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: John 14 Октябрь 2007, 21:21
|
Hi,
I have stumbled across this forum. I have had experience with Taylor Spatial Frame. As a matter of fact my tibia was severely damaged. Luckily I got one of these fixators fitted on. I think the ring fixators offer better mechanical conditions at fracture site of long bones. For other types of bones this might not be the case.
I found very helpful the information provided on the www.bonefixator.com . Check out there the sections on bone healing, fractures, and fixation methods to get better understanding why and when to use external ring fixation.
I hope this helps for people who are still looking at this forum.
John
|
[
Ответить ]
|
|
Re: Ilizarov vs Orthofix
Popov Victor 01 Май 2006, 08:39
|
Dear Colleague Nicola Papapietro. En 1985 j'apprenais deux mois chez Ilisarov avec l'orthopédiste de l'Italy Ferdinando del Prete. Je veux trouver Ferdinando del Prete. Popov Victor. Kazakstan. Karaganda. popov_cpl@mail.ru
|
[
Ответить ]
|
Re: Ilizarov vs Orthofix
Отправитель: Nicola Papapietro 01 Май 2006, 20:43
|
Cher Confrere
ceci c'est l'addresse du docteur Del Prete. J ne connais pas lui, mais vous pouvez ecrire a lui. Ie n'ai pas l'e-mail ou le numero du telephone,
seulement l'addresse postale:
Dott. Ferdinando Del PreteVia S. Felice A Ema 35
50125 Firenze
Bonne chance
A bien revoir
Nicola Papapietro
|
[
Ответить ]
|
|
Re: Ilizarov vs Orthofix
john 26 Февраль 2010, 23:52
|
Well both fixators can work. It all depends on the interfragentray motion and mechanical enviroment at the frature site. check out for more information http://www.bonefixator.com
|
[
Ответить ]
|
